Max Swing: 33.46″
Max Turning Diameter: 31.5″
Max Turning Length: 118.3″
Spindle Bore: 5.5″
X-Axis Travel: 15.7″+1″
Z-Axis Travel: 122″
Spindle Speed: 15-1,500 RPM
Chuck Size: 15″
Spindle Nose: A2-11
Number of Tool Stations: 12
Shank Height for Square Tool: 1.26″
Shank Diameter Boring Bar: 1.9″
X/Z Axis Motor 5.4/9.4 HP
Approx. Weight: 44,500 lbs

Equipped With:
Fanuc Oi-TB Control
Tailstock
