GENERAL INFORMATION

• Manufacturer: Horizon

• Model: HT-30C

• Year: 2016

• Type: Three-sided automatic book trimmer

• Condition: Used (sold as-is)

• Operating Hours / Usage: 414,369 books trimmed

SPECIFICATIONS

• Trimming Method: Single-knife three-side trimming system

• Maximum Trim Thickness: 51 mm (2.0″)

• Book Processing: Continuous variable thickness handling

• Clamping System: Pressure clamp with rotation for sequential trimming (top, fore-edge, bottom)

• Knife Operation: Hydraulic

• Book Clamping: Hydraulic (A & B clamp plates included)

CONTROL SYSTEM

• pXnet binder control system

• Job scheduling and tracking capability

• Integrated production workflow management

POWER

• Electrical Requirement: 3-phase, 220V

FEATURES

✓ Fully automatic three-side trimming in one cycle

✓ Servo-driven precision trimming system

✓ Hydraulic clamp and knife operation for stability and force

✓ High-speed continuous production capability

✓ Interlocked safety covers for operator protection

✓ Integrated feed table and stacker system

✓ Capable of handling variable book thickness without manual adjustment

✓ Production tracking via pXnet system

EQUIPPED WITH

• A clamp plates

• B clamp plates

• Feed table system

• Integrated stacker

• Safety interlock enclosure system

APPLICATIONS

• Bookbinding production lines

• Commercial print finishing

• High-volume publishing operations

• Print-on-demand trimming workflows

• Industrial bindery automation
