Datron Neo Series 2 CNC High Speed Milling Machine Single Phase – Year 2020
Overall machine dimensions are 1950mm tall 1297 mm long and 805mm wide

Power: 240V Single Phase

Control Software: Datron NEXT
Operating Terminal: 24″ multi-touch screen
Traverse Path (X, Y, Z): 20.5″ × 16.5″ × 8.7″
Working Area (X, Y, Z): 19.7″ × 15.7″ × 6.9″
Spindle: Upgraded 2 kW, 40,000 RPM Jäger High-Frequency, direct shank
Tool Magazine: 24-station with cover and automatic tool setter
Feed Rate: 1,102 in/min
Positioning Rate: 1,102 in/min
Drive System: Brushless digital servo drives; directly driven ball-screw spindle drives for each axis
Weight: Approx. 1,543 lbs

Control Software: Datron NEXT
Operating Terminal: 24″ multi touch screen
Traverse path (X,Y,Z) 520mm X 420mm X 220mm
Working Area (X,Y,Z) 500mm X 400mm X 175mm
Spindle: Upgraded 2kW 40,000 RPM Jager High Frequency, direct shank
24 station tool magazine with cover and automatic tool setter
Feed Rate: 28 m/min
Positioning rate: 28 m/min
Drive System: Brushless digital servo drives; directly driven ball-screw spindle drives for each axis
Weight: Approx 700 kg
